ENGLISH
10
2 Inserting Disc
q Press the OPEN/CLOSE button ( 5 ) to open the disc tray.
w Insert a disc in the appropriate recess in the tray, label side
up.
e Press the OPEN/CLOSE button ( 5 ) to close the tray.
• “Close” lights up, followed by “TOC Reading”
and the display will show the type of disc you inserted.
• If you insert a blank or partly-recorded CD-R or
unfinalized CD-RW, the CD recorder will calibrate the
disc for optimum recording. During this process the
display will first show “Now OPC” and then the
number of audio tracks. Calibration can take up to 60
seconds. (CD-R/RW)
• If a CD-R/RW is finalized it will show “CD” on the
display.
Recess
Disc tray
NOTES:
• If your finger should get caught in the disc tray when it closes, press the OPEN/CLOSE button (
5 ).
• For recording it is important that the blank disc is completely free from dust particles or scratches. See “Disc cleaning”
on Page 6.
• When text information is entered but not finalized, the disc holder will not open until all of the text information has been
deleted.
“Text Erase OK?” will be displayed for 2 seconds. When the enter button is pressed during this interval, the text
information will be deleted and the disc holder can be opened.
8 SETUP METHOD
★ The 10 items listed below can be set with the setup menu. The following messages will be displayed for the various setting
items.
• Close the disc trays and set the stop mode for both the CD and CD-R sections.
• The contents of the set menu are stored, but this data might be lost if the unit is disconnected from the power source for 2 to 3
days.
q “Sync. Rec?”…………………………………………… Synchro recording mode.
w “Sync. Level?” ……………………………………… Synchro recording level.
e “A.T. Mark?”…………………………………………… Auto track mark.
r “FadeIn Time?” ……………………………………… Fade-in recording time.
t “FadeOutTime?” …………………………………… Fade-out recording time.
y “Intro Time?”………………………………………… Scan recording intro time.
u “Custom Index” ……………………………………… Custom index.
i “Skip Play?”…………………………………………… Skip play.
o “Timer Play?”………………………………………… Timer playback.
!0 “SCMS Set?” …………………………………………… Copy management.
OPEN/CLOSE button
(
5 )
(1) Setup Method
STOP PAUSE PLAY
2
4
3
7 8
5 6
1
9
10 + 10
REC
ENTER
MENU
8 9
3 2
6 7
PROG/DIRECT CALL
RANDOM
DISPLAY SEL FADER INPUT FINALIZE
1 / ALL A - B
CHARACTER TIME TITLE
M + ✽ –
CLEAR CLEAR
A ! "
J ( )
D # % G & '
P ,
Y < < > V : ; S .
[ = ] { ? }
OPEN / CLOSE
TIME TIME CLEAR INPUT
MENU
5
OPEN /CLOSE
5
PROFESSIONAL CD RECORDER DN-C550R
PHONES PHONES LEVEL
MIN MAX
POWER
ON OFF
FINALIZE
MULTI JOG
3 1 2 3 1 2
REMOTE SENSOR
PLAY STOP PAUSE
HIGH NORMAL DUBBING 8 9
RELAY MODE
DISPLAY
SELECT TITLE / CHARACTER
PUSH
ENTER
8 9
PLAY STOP PAUSE
4 REC
- +
2
3
2 1 2,3 2
1 Switch on the power.
2 Press the menu button and turn the jog dial on the main unit or use the automatic search buttons on the remote control
unit to display “Setup Menu?”.
3 Press the enter button and enter the setup mode.
(2) Setting the Synchro Recording Mode
★ Perform the synchro recording mode settings. (See Page 18.)
STOP PAUSE PLAY
2
4
3
7 8
5 6
1
9
10 + 10
REC
ENTER
MENU
8 9
3 2
6 7
PROG/DIRECT CALL
RANDOM
DISPLAY SEL FADER INPUT FINALIZE
1 / ALL A - B
CHARACTER TIME TITLE
M + ✽ –
CLEAR CLEAR
A ! "
J ( )
D # % G & '
P ,
Y < < > V : ; S .
[ = ] { ? }
OPEN / CLOSE
TIME TIME CLEAR INPUT
MENU
5
OPEN /CLOSE
5
PROFESSIONAL CD RECORDER DN-C550R
PHONES PHONES LEVEL
MIN MAX
POWER
ON OFF
FINALIZE
MULTI JOG
3 1 2 3 1 2
REMOTE SENSOR
PLAY STOP PAUSE
HIGH NORMAL DUBBING 8 9
RELAY MODE
DISPLAY
SELECT TITLE / CHARACTER
PUSH
ENTER
8 9
PLAY STOP PAUSE
4 REC
- +
1,2,3,4
2,4
1,3
1 Set the unit to the setup mode, then turn the jog dial of the main unit or press the automatic search button of the
remote control to display “Sync. Rec?”.
2 Press the enter button and set the synchro recording selection mode.
3
Turn the jog dial of the main unit or press the automatic search button of the remote control, then select the synchro
recording mode.
“Sync. Off?”.
“Disc Sync.?”.
“Make CD?”.
“1Tr Sync.?”.
4
Press the enter button and set the synchro recording mode.
“Synchro Off”.
“Disc Synchro”.
“Make CD”.
“1Tr Synchro”.
