Connection Ports
12
11
10
9
8
7
6
5
4
3
2
1
1.
Power Socket
2.
3D Sync Out (5V) connector
3.
HDMI 2 Connector (v1.4a 3D supported)
4.
HDMI 1 Connector (v1.4a 3D supported)
5.
USB for firmware upgrad
6.
VGA-IN/YPbPr/
7.
RS-232 Connector (9-pin)
8.
Component Video Input Connector (YPbPr)
9.
USB for Power ([email protected])
10. Kensington Lock Port
11.
Composite Video Input Connector
12. 12V OUT (12V, 500mA, 3.5mm mini jack)
