Example illustration: Map with route guidance
inactive and with the menu system hidden (full
screen map display)
:
Current vehicle position
;
Map orientation ( Y page 90)
=
Map scale ( Y page 89)
Hiding or showing the menu system
X Hiding: Slide Z V.
The Full Screen menu item appears in
the main area of the display.
X Press W.
or
X Press and hold back button % in the
center console (
Y page 75).
The menu system is hidden. The map can
be seen in the full screen.
X Showing: Press W in the full-screen map
display.
Adjusting the map scale
i It is only possible to adjust the map scale
with the menu system hidden (full-screen
map display).
X Rotate c V d until the desired map scale is
set.
: Currently set map scale as number
;
Scale
= Pointer indicating the currently set map
scale
?
Previously set value (only visible when the
setting has been changed)
As soon as you rotate c V d , scale ; appears.
Rotating clockwise zooms out, rotating
counterclockwise zooms in.
Saving current vehicle position as
destination in last destinations list
X Showing menu system, if necessary:
Press W.
X Saving: Select Position Q Store
Vehicle Position.
COMAND saves the current vehicle
position as a destination in the last
destinations (
Y page 134).
i The cross hair may not be visible when
using this function. Otherwise the position
of the cross hair will be stored.
Moving the map
i It is only possible to move the map with
the menu system hidden (full-screen map
display).
X Slide Z V Æ , X V Y or a V b .
A cross hair appears on the map.
COMAND navigation (introduction)
89
