SPECIFICATIONS
31
CL800 CL1200 CL1600 CL2000
Load Impedance 2 Ω 4 Ω 8 Ω 2 Ω 4 Ω 8 Ω 2 Ω 4 Ω 8 Ω 2 Ω 4 Ω 8 Ω
Max. Midband
Output Power
THD = 1%, 1kHz , Dual Channel
600W 400W 240W 900W 600W 350W 1100W 800W 500W 1500W 1000W 600W
Rated Output Power
THD < 0,1%, 20Hz … 20kHz
--- 300W 150W --- 500W 250W --- 700W 350W --- 850W 450W
Max. Single Channel
Output Power
Dynamic Headroom, IHF-A
1100W 580W 300W 1450W 850W 450W 2200W 1200W 625W 2700W 1450W 750W
Max. Single Channel
Output Power
Continuous, 1kHz
800W 480W 270W 1200W 720W 410W 1500W 950W 550W 1900W 1150W 650W
Max. Bridged
Output Power
THD = 1%, 1kHz
--- 1200W 800W --- 1800W 1200W --- 2200W 1600W --- 3000W 2000W
Maximum RMS Voltage Swing
THD = 1%, 1kHz
50V 62V 72V 80V
Power Bandwidth, ref. 1kHz
THD =1%, half power @ 4 ohms
10Hz … 60kHz
Voltage Gain, ref. 1kHz 32,0 dB
Input Sensitivity
at rated output power
+1,15 dBu (0,88 V rms) +3,2 dBu (1,12 V rms) +4,7 dBu (1,33 V rms) +5,5 dBu (1,46 V rms)
THD at rated output power
MBW = 80kHz, 1kHz
< 0,05%
IMD-SMPTE, 60Hz, 7kHz < 0,02%
DIM 30, 3,15kHz, 15kHz < 0,01%
Maximum Input Level +22 dBu (9,76 V rms)
Crosstalk
ref. 1kHz, at rated output power < -80 dB
Frequency Response
ref. 1kHz (- 1dB)
15Hz … 40kHz
Input Impedance
active balanced
20 kΩ
Damping Factor, 1kHz > 300
Slew Rate 25 V/µs 30 V/µs 35 V/µs 35 V/µs
Signal to Noise Ratio, Amplifi er
A-weighted
103,5 dB 105,5 dB 107,0 dB 109,0 dB
Output Noise, A-weighted < -70 dB
Output Stage Topology Class AB Class H Class H Class H
Power Requirements 100V, 120V, 220V, 230V, 240 V; 50Hz … 60Hz (factory confi gured)
Power Consumption 1/8 max.
output power @ 4 ohms
600W * 500W * 660W * 725W
Protections Audio limiters, High temperature, DC, HF, Back-EMF,
Peak current limiters, Inrush current limiters, Turn on delay
Cooling Front-to rear, 3-stage fans
Ambient Temperature Limits +5°C ... +40°C (40°F ... 105°F)
Safety Class I
Dimensions (W x H x D) mm 483 x 88,1 x 386,8
Weight 13,5 kg (30,8 lbs) 15 kg (33 lbs) 16 kg (35,2 lbs) 18 kg ( 39,6 lbs)
Optional:
Rear-rackmount 15,5“
Rear-rackmount 18“
LPN + Lo-Cut internal fi lter-card
D112930 (NRS 90262)
D112933 (NRS 90264)
D112963 (NRS 90268)
* Measured with 110% of rated mains voltage
Notes:
- Depending on the ambient temperature, the unit might not operate continuously at 2
Ω load in Dual Mode or 4Ω load in Bridged Mode.
- Amplifi er at rated conditions, both channels driven, 8 Ω load, unless otherwise specifi ed.
