PART NUMBERING SYSTEM
E 48 S B
9R6
25 N R
F
A
Type of
Product
Input
Voltage
Number of
Outputs
Product
Series
Output
Voltage
Output
Current
ON/OFF
Logic
Pin Length
Option Code
E- Eighth
Brick
48- 38V~55V
S- Single B- Bus
Converter
9R6- 9.6V
25- 25A
N- Negative
P- Positive
R- 0.170”
N- 0.145”
K- 0.110”
F- RoHS 6/6
(Lead Free)
A - OCP, OTP
hiccup
B - OCP, OTP
latch-up
C - Latching OCP
and Non-latching
OTP
MODEL LIST
MODEL NAME
INPUT
OUTPUT
EFF @ 100% LOAD
E48SB9R625NRFA 38V~55V 6.65A 9.6V 25A
240W
96.5%
E48SB9R625PRFC 38V~55V 6.65A
9.6V 25A
240W
96.5%
E48SB12020NRFA 38V~55V 6.5A
12V 20A
240W
96.3%
Note:
1. Default remote on/off logic is negative;
2. Default Pin length is 0.170”;
3. Default OTP and output OVP, OCP mode is auto-restart.
4.
For different option, please refer to part numbering system above or contact your local sales office.
