GENERAL SPECIFICATIONS
GENERAL SAFETY PRECAUTIONS
CAUTION
Some product assemblies can exceed
45 lbs. Use lifting aids and proper lifting
techniques when installing, removing, or
placing in service.
CAUTION
Watch for sharp features when
interacting with this product. The parts
have complex shapes and machined
edges.
WARNING
This product is capable of emitting
a spark if misused, therefore it is not
recommended for use in any explosive
environment.
CAUTION
Use
appropriate
guarding
from
applications using an output shaft.
Failure to guard could result in serious
bodily injury.
CAUTION
CAUTION
Use appropriate guarding from
applications using an output shaft.
Failure to guard could result in serious
bodily injury.
The temperature limits for the
product are 4.5-100 degree
Celsius (40-220 degree F).
Specifications
Torque:
Up to 390 Nm (3450 in-lbs)
Actuation Pressure:
1 - 5.5 bar (14.5 - 80 psi)
Service Temperature:
4.5 - 104 C (40 - 220 F)
Approximate Weight:
Up to 20.4 kg (45 lbs)
WARNING
Ensure proper guarding of the product is
used. Nexen recommends the machine
builder design guarding in compliance
with OSHA 29 CFR 1910 “Occupational
Safety and Health Hazards”.
