Technical details
Operating Manual PMI 5
1002241­EN­05 48
Serial interface 264509 264515 264516 264518
Number of RS232
interfaces
1 1 1 1
Audio interfaces 264509 264515 264516 264518
Number 1 1 1 1
Environmental data 264509 264515 264516 264518
Ambient temperat­
ure
Temperature
range
0 ­ 50 °C 0 ­ 50 °C 0 ­ 50 °C 0 ­ 50 °C
Storage temperature
In accordance
with the standard EN 60068­2­1/­2
EN 60068­2­1/­2 EN 60068­2­1/­2 EN 60068­2­1/­2
Temperature
range
­25 ­ 60 °C ­25 ­ 60 °C ­25 ­ 60 °C ­25 ­ 60 °C
Climatic suitability
In accordance
with the standard EN 60068­2­78
EN 60068­2­78 EN 60068­2­78 EN 60068­2­78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during
operation
Not permitted Not permitted Not permitted Not permitted
EMC EN 61000­6­2, EN
61000­6­4 EN 61000­6­2, EN
61000­6­4 EN 61000­6­2, EN
61000­6­4 EN 61000­6­2, EN
61000­6­4
Vibration
In accordance
with the standard EN 60068­2­6
EN 60068­2­6 EN 60068­2­6 EN 60068­2­6
Frequency 10,0 ­ 150,0 Hz 10,0 ­ 150,0 Hz 10,0 ­ 150,0 Hz 10,0 ­ 150,0 Hz
Acceleration 1g 1g 1g 1g
Shock stress
In accordance
with the standard EN 60068­2­27
EN 60068­2­27 EN 60068­2­27 EN 60068­2­27
Acceleration 15g 15g 15g 15g
Duration 11 ms 11 ms 11 ms 11 ms
Protection type
In accordance
with the standard EN 60529
EN 60529 EN 60529 EN 60529
Housing IP64 IP65 IP65 IP65
In accordance
with UL
1,2,5
1,2,5,4/4X indoor
use only
– –
Mechanical data 264509 264515 264516 264518
Dimensions
Height 87,0 mm 144,0 mm 165,0 mm 160,0 mm
Width 157,0 mm 170,0 mm 212,0 mm 232,0 mm
Depth 40,0 mm 40,0 mm 62,5 mm 62,5 mm
Weight 316 g 659 g 1.344 g 1.364 g
