List of figures – Fluke 787 User Manual
Page 7
v
List of Figures
Figure
Title
Page
1.
Fluke 787 ProcessMeter ........................................................................................................ 6
2. Input/Output Jacks................................................................................................................. 7
3. Rotary
Switch
Positions for Measurements ........................................................................... 9
4. Rotary
Switch
Positions for mA Output .................................................................................. 11
5. Pushbuttons .......................................................................................................................... 13
6. Elements
of
the Display ......................................................................................................... 15
7. Sourcing Current ................................................................................................................... 22
8.
Simulating a Transmitter ........................................................................................................ 24
9. Using
the Holster ................................................................................................................... 30
10. Replacing
the Battery ............................................................................................................ 31
11. Replacing a Fuse .................................................................................................................. 33
12. Replacement Parts ................................................................................................................ 36
