ProcessMeter™
Specifications
37
Specifications
All specifications apply from +18
°
C to +28
°
C unless
stated otherwise.
All specifications assume a 5 minute warmup period.
The standard specification interval is 1 year.
Note
“Counts” means number of increments or
decrements of the least significant digit.
DC Volts Measurement
Range (V dc)
Resolution
Accuracy,
±
(% of Reading + Counts)
4.000
0.001 V
0.1 % + 1
40.00
0.01 V
0.1 % + 1
400.0
0.1 V
0.1 % + 1
1000
1 V
0.1 % + 1
Input impedance: 10 M
Ω
(nominal), <100 pF
Normal mode rejection ratio: >60 dB at 50 Hz or 60 Hz
Common mode rejection ratio: >120 dB at dc, 50 Hz, or 60 Hz
Overvoltage protection: 1000V
