787
Users Manual
12
Table 4. Rotary Switch Positions for mA Output
No. Position Default Function Pushbutton Actions
 OUTPUT
[ mA
Test leads in SOURCE:
Source 0 % mA
Test leads in
SIMULATE:
Sink 0 % mA
% STEP X or W: Adjusts output up or down to the next 25 % step
COARSE Z or Y: Adjusts output up or down 0.1 mA
FINE X or W: Adjusts output up or down 0.001 mA

OUTPUT
mA
J Test leads in SOURCE:
Source repeating
0 % -100 %-0 %
slow ramp (E)
Test leads in
SIMULATE:
Sink repeating
0 % -100 %-0 %
slow ramp (E)
BLUE cycles through:
• Fast repeating 0 % -100 % - 0 % ramp (P on display)
• Repeating 0 % -100 % - 0 % ramp in 25 % steps (N on display)
• Slow repeating 0 % -100 % - 0 % ramp (E on display)
