787
Users Manual
14
Table 5. Pushbuttons (cont.)
No. Pushbutton
Function(s)
X
M
% STEP
Measuring: Selects a MIN, MAX, or AVG action (see pg. 18)
mA Output: Adjusts mA output up to the next higher 25% step
Z
K
COARSE
Measuring: Selects a fixed range (hold for 1 second for auto range)
mA Output: Adjusts output up 0.1 mA
X
I
FINE
Measuring: Toggles TouchHold, or in MIN MAX recording, suspends recording
mA Output: Adjusts output up 0.001 mA
FINE
F
W
Measuring: Toggles between frequency counter and ac voltage measurement functions
mA Output: Adjusts output down 0.001 mA
COARSE
C
Y
Measuring: Toggles relative reading (sets a relative zero point)
mA Output: Adjusts output down 0.1 mA
% STEP
T
W
Measuring: Toggles between
Ω
measure and continuity functions
mA Output: Adjusts mA output down to the next lower 25 % step
