787
Users Manual
8
Table 2. Input/Output Jacks
Item Jack Measurement Functions Source Current Function
Simulate Transmitter
Function
 c A Input for current to 440 mA
continuous. (1A for up to 30
seconds.) Fused with a 440 mA
fuse.
Output for dc current to 24 mA.
 d mA Input for current to 30 mA.
Fused with a 440 mA fuse.
Common for dc current output to
24 mA.
Output for transmitter
simulation to 24 mA. (Use in
series with an external loop
supply.)
 V Input for voltage to 1000V,
Ω ,
continuity, and diode test.
 COM Common for all measurements.
Common for transmitter
simulation to 24 mA. (Use in
series with an external loop
supply.)
