XAIRCRAFT X650 Value - Manual (Page 20)

袋编号
Packet
物料编号
Product Code
名称 Name
数量
Amount
E1
E1001
XAircraft FC1212
飞行控制器 XAircraft FC 1212
Flight Controller
1
E1002 3-pin 信号线 3-pin Signal Cable 6
E1003
减震海绵
(10Ч35Ч0.5mm) Shock Absorber Sponge
(10Ч30Ч0.5mm)
1
E2
E1004
XAircrft AHRS-S V2
姿态传感器
XAircraft AHRS-S V2
Attitude and Heading
Reference System 1
E1005
减震海绵
(30Ч30Ч2mm) Shock Absorber Sponge
(30Ч30Ч2mm)
1
E1006 6-pin 信号线 6-pin Signal Cable 1
E3007
XAircrft BLC-10A
高速无刷电调 XAircraft BLC-10A
UltraPWM Brushless ESC
4
E3008 1转5电源转接线 1-to-5 Power Wire 1
E4
E1009 XAircraft USB-Link XAircraft USB-Link 1
E1010 USB线 USB Cable 1
E1011 4-pin 信号线 4-pin Signal Cable 1
F1
F3001C 机身上板 Fuselage Upper Plate 1
F3002C 机身下板 Fuselage Lower Plate 1
F3004C AHRS固定板 AHRS Mounting Plate 1
F3005C 电池板 Battery Mounting Plate 1
F3006C 电机固定板 Motor Mounting Plate 4
L1010 扎带 Fastener 2
F3007 机身盖 Frame Cover 1
F2
F3008 电机夹头 Motor Mount 4
F3009 机身杆夹头 Arm Mount 4
F3010 挂载固定件 Load Hanger 2
F3011 机身固定件1 Fuselage Strut 1 2
F3012 机身固定件2 Fuselage Strut 2 2
F3013 ESC电调盖 ESC Cover 4
F3014C 机身管 Frame Arm 4
F3015 机身管支撑件1 Frame Arm Strengthener 1 4
F3016 机身管支撑件2 Frame Arm Strengthener 2 4
L3001C 起落架横杆 Landing Gear Skid Pipe 2
L3002C 挂载杆(含管塞)
Load Mounting Pipe(with
Cork)
2
L3003 挂载杆固定件 Load Mounting Pipe Mount 4
L3004 挂载杆固定胶 Load Mounting Pipe Fixer 4
L3005 起落架 Landing Gear 2
P3001 XAircraft 2215 无刷电机 XAircraft 2215 Brushless Motor 4
P3002-A XAircraft 10寸螺旋桨(正)
XAircraft 10inch Clockwise
Blade
2
P3002-B XAircraft 10寸螺旋桨(反)
XAircraft 10inch Counter
Clockwise Blade
2
P3003 桨夹 Blade Locker 4
M
M3001 M2.5×6 圆头内六角螺丝 M2.5×6 Socket Screw 40
M3002 M2.5×20 杯头内六角螺丝 M2.5×20 Socket Screw 4
M3003 M3×6 圆头内六角螺丝 M3×6 Socket Screw 8
M3004 M3×8 圆头内六角螺丝 M3×8 Socket Screw 8
M3005 6Ч2.5Ч0.5mm垫片 6Ч2.5Ч0.5mm Washer 8
M3006 M3×8 尼龙螺丝 M3×8 Nylon Screw 4
M3007 M3×12 尼龙支柱 M3×12 Nylon Pillar 12
M3008 6Ч3Ч1.5mm尼龙垫片 6Ч3Ч1.5mm Nylon Wahser 8
M3009 M3 尼龙螺母 M3 Nylon Nut 4
M3010 M2.5×22 杯头内六角螺丝 M2.5×22 Socket Screw 4
附赠包1 附赠包1 Steel Screw Pack 1
附赠包2 附赠包2 Nylon Screw Pack 1
赠送 方向识别贴纸 Heading Paster 1
袋编号
Packet
物料编号
Product Code
名称 Name
数量
Amount
零部件清单 Parts List
18 www.xaircraft.com
