DT395BT
ENGLISH 2
The DT395BT Battery and Power Management
The DT395BT is equipped with an internal Li-Ion battery pack and an optional battery
pack that clips (hot-pluggable) onto the back of the tablet. The period between battery
recharges can be significantly lengthened by putting the tablet into Standby mode
through the Power Button (see Buttons Function Table) whenever the tablet is not in
use. Depending on the operating software, the DT395BT may also be configured to enter
various power-saving modes via the Power Button or through timed entry.
Half Slot Smart Card Reader and SD Card Reader
The DT395BT comes with a half slot smart card reader.
Remove the rubber cover and insert a card (Picture 1). •
Pull to remove the card (Picture 2). •
Remove the rubber cover and insert a SD card (Picture 3). •
Push, release and remove the card (Picture 4). •
(Picture 1)
(Picture 3)
(Picture 2)
(Picture 4)
3 ENGLISH
Button Functions
BUTTON ACTION
Security button.
As scanner trigger when equipped with the scanner module
Power on.
Push/release typically enters Standby mode, or Push/release exits Standby mode or
restarts (software dependent)
Push and hold (over 4 seconds) invokes hardware shutdown
Battery/Power LED
Wireless LED
1
1
2
2
Input/ Output Ports
Wireless Switch
Headphone Jack
USB Port
DC Power Input
Half Slot Smart Card Reader and SD Card Reader
A
C
D
E
B
A
B
C
D
E
