WebDT DT311C/ DT311H - Manual (Page 3)

DT311C/ DT311H
ENGLISH 4
OPERATION
Internal Battery
Warning! !
The Internal battery pack should only be replaced by an authorized DT Research service
representative. Please contact your product and/or service provider for internal battery
replacement service.
Powering ON and OFF
To activate the Tablet Modules basic, push and quickly release the Power Button. The
display will come on in a few seconds. To put the DT311C/ DT311H in Standby mode,
push and quickly release the Power Button. To turn the DT311C/ DT311H off for extended
storage, power off safely using any software function that “shuts down computer”
provided in the software operating system.
NOTE:
The battery packs shipped with your tablet may be low in power—please use the
AC-DC adapter with the DT311C/ DT311H when setting up for the first time to
fully charge the internal battery pack. You may charge the external battery pack
with it attached to the DT311C/ DT311H, or with the optional external battery
charger kit.
NOTE:
When the battery pack(s) is (are) charging, the blue-colored Battery LED should
blink slowly. If plugging in the AC-DC adapter does not trigger this blinking
activity and the LED stays dark, the battery pack(s) may have been drained
substantially. Try unplugging/ replugging the AC-DC adapter to the DT311C/
DT311H a few times to activate the charging process.
NOTE:
To conserve power, use (push and quick release) the Power Button to put the
tablet in “Standby” mode while not in use. Pushing briefly on the same button
will wake up the system within seconds.
NOTE:
Avoid using the Power Button (“hold 4+ seconds” feature) to turn off the
tablet—this form of hardware shutdown is intended to be a means of recovery
from lockups, and not as normal operation.
5 ENGLISH
Start Up
If the power up (from Standby or otherwise) is successful, the appropriate interface will
be displayed after a launch sequence of several seconds. The wireless LAN connection
may take 10-15 seconds to be established.
Configuring the Mobile Tablet
The DT311C/ DT311H may be configured using the utilities and methods dictated by
the software operating system. The DT311C/ DT311H should be configurable for various
properties such as user profiles, network features, and several system elements.
Wireless Networking
Wireless LAN
The DT311C/ DT311H is often delivered with an embedded (user-inaccessible) 802.11ac/
a/b/g/n WLAN adapter equipped with a hidden custom antenna.
T • hrough the support of typical WLAN adapters, the DT311C/ DT311H should be able
to detect all 802.11 access points in the vicinity for you to select the access point of
your choice for connection.
T • he SSID and WEP/WPA/WPA2 (if enabled) parameters on the DT311C/ DT311H and
the access points have to match. The SSID is case-sensitive and it is recommended
that you enable WEP/WPA/WPA2 encryption (or advanced alternatives) for secure
access.
W • hen WEP/WPA/WPA2 is enabled, you may need to consult your network admin-
istrator or your networking equipment literature to properly configure associated
settings such as Authentication mode, etc.
R • efer to the access point operating manuals for setting up the 802.11 access points.
