8N301-150 POWER COOLER ASSY, C5 CORVETTE 1
8N201-150 DISCHARGE ASSY, C5 CORVETTE 1
8n101-150 AFTERCOOLER ASSY, C5 CORVETTE 1
4GL012-030 ELBOW, 3.88" - 3.0" x 90° LS1 TRK 1
7R002-044 #44 GOLdSEAL HOSE CLAMP 4
7R002-048 #48 GOLdSEAL HOSE CLAMP 1
7R002-064 #64 GOLdSEAL HOSE CLAMP 1
4GR012-030 diSCHARGE TUBE 1
7S275-200 2-3/4" x 2" SLEEVE 2
8d001-001 STd COMP BYPASS VALVE 1
7R002-016 #16 GOLdSEAL HOSE CLAMP 4
7R001-008 #8 STnLS HOSE CLAMP 2
7P062-187 1/16"nPT x 3/16" HOSE BARBEd 1
7P500-016 TEE, .5" x .5" x 1/16"nPT METAL 1
7U030-046 5/32" VACUUM LinE 6'
7U034-016 1" GS HOSE 0.333'
7U133-100 HOSE, ELBOW, 90°,1"id, MOLdEd 1
8N107-150 WATER PUMP ASSEMBLY, C5 CORVETTE 1
5W001-005 3/8" PLASTiC WiRE LOOM 8'
5W001-009 16-14GA MALE SLidE inSULATEd 2
5W001-010 16-14GA FEMALE SLidE inSULATEd 5
5W001-011 16-14GA EYELET .25" HOLE 2
5W001-014 FUSE HOLdER 10GA WiRE 1
5W001-015 FUSE, BLAdE TYPE 20AMP 1
5W001-016 RELAY, BOSCH 1
5W001-017 3/8" RinG TERMinAL 12GA 1
5W001-024 Mini ATC FUSE TAP 1
5W001-025 FEMALE SLidE,inSULATEd, Mini 1
5W001-040 12-10GA FEMALE SLidE inSULATEd 1
5W014-010 14GA STRd WiRE REd, UL1015 8'
5W014-030 14GA STRd WiRE BLACK 2'
5W016-010 WiRE, STRnd, 16AWG, YELLOW 1'
7R003-027 AdEL CLAMP, 1-11/16" 1
7U100-044 TiE-WRAP, 4" nYLOn 8
8F001-402 PUMP, WATER, PiERBURG 1
8N106-150 WATER COOLER ASSY 1
8n006-010 WATER COOLER 1
7A250-074 1/4-20 x 3/4" HXHd PLT 2
7F250-021 1/4-20 nYLOCK nUT ZinC PLTd 2
7J250-001 1/4" SAE WASHER, PLTd 2
7J250-150 1/4" FEndER WASHER 2
8N105-150 WATER TANK MTG ASSY, C5 CORVETTE 1
4GR010-060 BRKT, WATER RES, C5 CORVETTE 1
8n055-030 TAnK, LT1 AFTERCOOLER 1
7A250-050 1/4-20 x 1/2" SHCS ZinC PLTd 4
7J006-093 6mm WASHER, PLATEd 4
7P375-075 3/4" HOSE BARB UniOn, BRASS 1
7P500-026 1/2"nPT x 3/4" BARB 90° 7
7P500-078 1/2"nPT x 3/4" HOSE FiT 1
7R007-001 nYLOn CLAMP 1-1/8" 12
7U030-065 3/4" x 90° HOSE SHORT 1
7U038-000 3/4" HEATER HOSE 17'
7U038-012 HOSE, Ø3/4" 90°,4 x 12" 1
7E010-075 #12 x 3/4" SHT METL SCRW HEX 3
8N104-150 SUPPORT COMPONENTS, C5 CORVETTE 1
7A250-050 1/4-20 x 1/2" SHCS ZinC PLTd 2
7J006-093 6mm WASHER, PLATEd 2
7U100-044 TiE-WRAP, 4" nYLOn 5
7U100-055 TiE-WRAP, 6" nYLOn 10
8n055-050 PLASTiC CAP, SURGE TAnK 1
8n056-060 SURGE TAnK, PLASTiC 1
PART NO. DESCRIPTION QTY.
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or damaged parts immediately.
2001-2004 Corvette LS6 Z06
Part No. 4GR218-010SQ
®
ENGINEERING, LLC
PARTS LIST
