Vortech Universal Small Block Chevy Carbureted - Manual (Page 7)

P/N: 4GP020-015, v3.0, 2012-03-26
©2012 Vortech Engineering, Inc.
All Rights Reserved, Intl. Copr. Secured
vii
®
ENGINEERING, INC
Part No. DescriPtioN Qty Part No. DescriPtioN Qty
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or damaged parts immediately.
2e128-040 s/c cHeV UNiV carB, GeN2 V2 1
2a032-333 s/c DriVe PLy, 3.33" 10-GrV 1
8r101-003 PULLey retaiNer asy, 10-riB 1
7U100-071 KEY, 3/16"SQ x 1-1/8" LONG 1
2A040-011 PULLEY RETAINER S/C 1
7B375-150 3/8-24 x 1-1/2" GR8 HX 1
7K375-040 3/8"AN960 FLAT WASHER, PLATED 1
8M001-060 caBLe, tHrottLe 1
8M010-170 BrKt, cHVy tHrottLe caBLe 1
8M205-012 carB eNcLosUre asy 1
007051 CARB ENCL ASY, UNIV SAT, G2 L 1
7A312-078 5/16-18 x 3/4" SHCS, S'STL 16
7A312-253 STUD, 5/16" x 2-1/2" CARB ENCLOSURE 4
7C011-050 10-32 PLUG SCREW 1
7F312-024 5/16-24 JAM NUT 4
7J312-000 5/16" FLAT WASHER, SAE 4
7J375-024 3/8" COPPER WASHER 4
7K312-030 5/16"AN WASHER, SS 12
7P187-102 -3 BULKHEAD FITTING TO 1/4" HOSE 1
7P187-103 PLUG, -3 O-RING PORT 3
7P250-120 1/4"NPT PIPE PLUG 1
7P375-104 PLUG, 3/8-16, BRASS SHORT 4
7PP500-087 PLUG, AN-8 O-RING PORT 3
7U100-003 O-RING 3 - 903 4
7U100-008 O-RING 3 - 908 3
7U100-020 10-32 GASKET 1
8M001-018 GASKET, 90mm THROTTLE BODY 1
8M003-051 MACH, MONDO COOLER COVER2 1
8M010-025 MORSE CABLE BRKT, CARB ENC 1
8M105-012 ENCL, STD. MACH ASY SAT. 1
8M110-010 ASY, THROTTLE LINK, CARB ENCLOSURE 1
8M001-017 HOLLEY 4-BARREL BASE GASKET 2
4GP111-031 MtG BrKt asy, sBc GeN2 1
4GP017-021 GM THROTTLE CABLE 1
4GP010-035 MOUNT PLATE, SBC UNIV, GEN2 1
2A017-751-05 SPACER, .750"OD x .360" LONG 2
2A041-594 BELT, K100594-GATES 1
7A375-500 3/8-16 x 5" HXHD GRADE-8 2
7A375-400 3/8-16 x 4" BOLT HXHD GR8 3
7A375-100 3/8-16 x 1" G5 HHCS, PLT 5
7A375-126 3/8-16 x 1.25" HHCS, GR8, PLT 4
4GB011-021 MOUNTING BRKT-MACH 1
7K375-040 3/8"AN960 FLAT WASHER, PLATED 14
7A375-475 3/8-16 x 4.75" HXHD GR8 PLTD 2
7A375-375 3/8-16 x 3-3/4" HXHD 3
7A375-112 3/8-16 x 1.125" FLT HD ALN 2
7A375-077 3/8-16 x 3/4" GR8 FLAT HD ZNC 1
7C080-030 M8 x 1.25" x 30 HXHD CL10.9 1
7C080-070 M8 x 1.25" x 70 HXHD ZINC 1
7F008-023 NUT, M8 x 1.25" x 70 HXHD ZINC 1
7J008-001 3/8" FLAT WASHER 2
PARTS LIST
4GP111-041 asy, MaN teNs. sBc GeN2 1
4MA116-160 IDLER ASY, MARINE GEN2 1
4FA011-032 BELT TENSIONER PLATE STD 1
4GP017-051 SPACER, 10-RIB MAN TENS. SBC 1
7A437-300 7/16-14 x 3.00" SHCS GR8 1
7C012-020 M12 x 1.75 x 20mm HXHD CL8.8 3
7J012-092 12mm WASHER, FLAT 3
7J438-072 7/16" WASHER, .94"OD x .109" THK 1
7J437-081 7/16"SAE WASHER PLATED 1
4GB130-026 oiL FeeD LiNe asy 1
70000 INSPECTOR NUMBER 0
7P125-026 1/8"NPT x #4 SAE FLARE, 90° 1
7P250-036 -4 SAE FLARE TO 1/4"NPT 1
7P250-066 -4 45° FEM SWIVEL x 1/4"NPT 2
7P250-080 1/4"NPT FEM. ELBOW, 90° 1
7P250-123 1/4"NPT x 1-1/2" PIPE NIPPLE 1
7P525-067 .525" CRIMP FERRULES 2
7U030-026 1/4" OIL FEED HOSE 3
7U100-055 TIE-WRAP, 7.5" NYLON 4
4GP130-036 oiL DraiN asy 1
7U030-036 1/2" OIL DRAIN HOSE 3
7P375-017 3/8"NPT x 1/2" BEADED HOSE BARB 1
7P375-033 3/8"NPT x 3/8"NPT SRT EL 2
7R001-008 #8 STNLS HOSE CLAMP 2
70000 INSPECTION NUMBER 0
7T640-011 PUNCH, OIL PAN FTG 1
4GP112-010 iNLet asy, s.B. cHeVy carB. 1
8H040-050 AIR FILTER 3.5" FLG. 7"L 1
4FA012-011 INTAKE TUBE, 180° w/o BOSSES 1
7S350-200 SLEEVE, 3-1/2" x 2" BLUE 1
7R002-056 #56 SAE TYPE “F” SS HOSE CLAMP 3
7R002-044 #44 SAE TYPE “F” SS HOSE CLAMP 1
75375-200 SLEEVE, Ø3.75" x 2.00" 1
75350-004 SLEEVE, Ø3.5" x 1" 1
7R002-060 #60 SAE TYPE “F” SS HOSE CLAMP 1
4GP112-040 DiscHarGe asy, sBc GeN2 sat 1
8M003-041 MACHINE, Ø3.5" FLANGE, SATIN 1
7S350-276 ELBOW, SIL Ø3.5" x 2.75" CHEVY CARB 1
7R002-056 #56 SAE TYPE “F” SS HOSE CLAMP 1
7R002-044 #44 SAE TYPE “F” HOSE CLAMP 1
4GP116-041 6" craNK PLy asy, sBc UNiV GeN2 1
4GP017-031 SPACER, SBC CRANK PULLEY, SERP 1
4MA018-041 6" CRANK PULLEY, UNIVERSAL 1
7B375-500 3/8-24 x 5.0" HXHD GR8 3
7B437-275 7/16-20 x 2.75" HXHD GR8 1
7J375-044 3/8"SAE WASHER, PLTD 3
7J438-081 7/16"SAE WASHER, PLATED 1
4GP017-041 SPACER, SBC CRANK PULLEY, V-BELT 1
7B375-475 3/8-24 x 4-3/4" HXHD GR8 3
4GP020-015 iNstr. MaNUaL, UNiV. sBc GeN2 Kit 1
008443 s/c race iNFo. PKG asy, VortecH 1
008130 LiceNse PLate FraMe, VortecH 1
008110 sMaLL siLVer Die-cUt DecaL 2
Universal Small Block Chevy Carbureted
V2 Si-TRIM
Part No. 4GP218-030SQ/038SQ
