Vortech Universal Small Block Chevy Carbureted - Manual (Page 10)

P/N: 4GP020-015 v3.0, 2012-03-26
©2012 Vortech Engineering, Inc.
All Rights Reserved, Intl. Copr. Secured
x
®
ENGINEERING, INC
Part No. DescriPtioN Qty Part No. DescriPtioN Qty
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or damaged parts immediately.
008118 DecaL, ViNyL, VortecH 1
008130 LiceNse PLate FraMe, VortecH 1
008445 1 yr s/c strt iNFor PKG asy VortecH 1
009035 s/c LUBe, BottLeD, Vort 3-PacK 1
2a046-580 BeLt, 4060580 GooDyear 1
2F328-070 V3 s/c asy, sBc eNtry LVL, sat, 3.33 PLy 1
4Fa111-032 s/c BeLt teNsNr assy, 6 riB 1
2A017-010 SPACER, IDLER PULY, 5.0 6 RIB 1
4FA011-042 BELT TENS PLATE, HEAVY DUTY 1
4FA016-150 IDLER PULY,6RIB 3 5" FLANGED 1
7C012-020 M12 X 1 75 X 20MM HXHD CL8 8 2
7C012-022 M12 X 1 75 X 20MM THIN HD 1
7C012-050 M12 X 1 75 X 50MM HXHD BOLT 1
7G010-175 12MM X 1 75 NUT 1
7J012-092 12MM WASHER, FLAT 1
4GP020-015 iNstr MaN, UNiV sBc GeN 2 Kit 1
4GP111-031 MtG BrKt asy, sBc GeN2 1
2A017-751-05 SPACER, .750"OD x .360" LONG 2
4GB011-021 MOUNTING BRKT-MACH 1
4GP010-035 MOUNT PLATE, SBC UNIV, GEN2 1
4GP017-021 SPACER, HEAD, SBC 360 THK 1
7A375-077 3/8-16 x 3/4" GR8 FLAT HD ZNC 1
7A375-100 3/8-16 x 1" G5 HHCS, PLT 5
7A375-102 3/8-16 X 1" FHCS, ZINC, PLT 3
7A375-123 3/8-16 X 1 25" FLT HD ALN 2
7A375-126 3/8-16 X 1 25 HHCS, GR8, PLT 4
7A375-375 3/8-16 x 3-3/4" HXHD 3
7A375-400 3/8-16 x 4" BOLT HXHD GR8 3
7A375-475 3/8-16 x 4.75" HXHD GR8 PLTD 2
7A375-500 3/8-16 x 5" HXHD GRADE-8 2
7C080-030 M8 x 1.25" x 30 HXHD CL10.9 1
7C080-070 M8 x 1.25" x 70 HXHD ZINC 1
7F008-023 NUT, M8 x 1.25" x 70 HXHD ZINC 1
7J008-001 3/8" FLAT WASHER 2
7K375-040 3/8"AN960 FLAT WASHER, PLATED 14
4GP112-050 assy, DiscH, sBc eNtry LVL 1
4GP012-050 DISCH TUBE, SBC ENTRY LVL,TUMBLED 1
7PS275-200 SLEEVE, BLACK 2 75ID X 2 0 1
7PS300-275 REDUCER, BLK Ш3 0-Ш2 75 1
7R002-044 #44 SAE TYPE “F” HOSE CLAMP 3
7R002-048 #48 SAE TYPE F SS HOSE CLAMP 1
4GP116-051 crK PLy asy, sBc UNiV eNtry 1
4GP017-031 SPACER, SBC CRANK PULLEY, SERP 1
4GP017-041 SPACER, SBC CRANK PULLEY, V-BELT 1
4MA018-031 CRANK PLY, 6-RIB, 6", UNIV 1
7B375-475 3/8-24 x 4-3/4" HXHD GR8 3
7B375-500 3/8-24 x 5.0" HXHD GR8 3
7B437-275 7/16-20 x 2.75" HXHD GR8 1
7J375-044 3/8"SAE WASHER, PLTD 3
7J438-081 7/16"SAE WASHER, PLATED 1
8H040-050 air FiLter 3 5"FLG X 7"L 1
8M106-011 assy, carB Hat 1
2H100-040 RETAINER, CARB HAT 10
7A250-051 1/4-20 X 50 HHCS GR5 ZINC PLT 10
7A312-276 5/16-18 X 2 75 SHCS GR8 ZINC 1
7J312-010 5/16" GASKET SEALING WASHER 1
8M001-025 GASKET, CARB BONNET BASE 1
8M006-011 HSG, MACH, CARB HAT 1
8M006-031 BASE, MACH, CARB HAT 1
8M011-020 DIFFUSER, CARB HAT, 8.25 OD 1
PARTS LIST
Universal Small Block Chevy Carbureted
V3 Si-Trim Entry Level Kit
Part No. 4GP218-050L/058L
