Vortech Ford Driver's Side Renegade System - Manual (Page 6)

P/N: 007062
©2003 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
28JAN03 v2.0
(DS Rngde S/C Sys(7062 v2.0))
2A158-040 S/C V-7 YS 1
4FP130-011 OIL FEED/DRAIN ASSY 1
4FP130-026 Oil Feed Line Assy 1
7P250-121 1/4 NPT Steel Nipple 1
7P250-122 1/4 Pipe Thrd AN 917 1
7P250-120 1/4 NPT Pipe Plug 1
7P125-103 -4 x 45
°
Male Elbow 1
7P250--36 -4 Flare To 1/4 NPT 1
4FP114-023 RADIATOR HOSE ASSY 1
4FP020-011 45
°
Thermostat 1
4FP040-050 Thermostat Gasket 1
4FP014-011 Radiator Pipe 1
7R002-020 #20 Goldseal Hose Clamp 3
7A312-100 5/16-18 x 1 HXCSGR5P 2
7K213-001 5/16 AN Washer 2
7R002-024 #24 Goldseal Hose Clamp 1
8E018-300 PULLEY PACKAGE, RENEGADE 1
2A038-300 S/C Pulley 3.00" 8 Groove 1
7A375-158 3/8-16 x 1/5" SOC HD GR8 Pltd 4
7K375-040 3/8 AN 960 Flat Washer 4
7L375-075 3/8 Lock Washer 4
4FA018-027 4.75" 8.0" 8Gv Crank Pulley 1
7U100-070 Key, 3/16 x 3/16 x 7/8 1
4FA111-042 S/C Belt Tensioner Assy, H.O. 1
2A048-565 Belt, 5080565-DAYCO "94 2.95" 1
2A040-011 Pulley Retainer S/C 1
7B375-125 3/8 24 x 1-1/4 HX CLS 1
7K375-040 3/8 AN 960 Flat Washer Plated 1
4FA111-071 MTG BRKT. ASSY DSIDE 1
4FP011-021 Mounting Brkt. Mach 1
7A375-100 3/8-16 x 1 G5 HXHD Plt 9
7K375-040 3/8 AN960 Flat Washer, Plated 17
7K437-001 7/16" AN Washer 2
7A437-750 7/16-14 x 7.25 HXHD GR8 2
4GF016-160 Pulley, Idler-Ribbed 1
2A017-017 Spacer, ACC Idler 5.0 Rngd 1
2A017-016 Shrt. ACC. Idler, V-3 1
7A375-250 3/8-16 x 2.5" GR5 HX 1
4FA017-061 Brkt Spacer, Renegade S/C 1
7A437-300 7/16-14 x 3.00 SHCS GR8 1
4FA010-051 Mntg Plt, S/C, Renegade Dual 1
4FA010-061 Suprt Plt, S/C, Renegade Dual 1
4FA017-081 Spacer, Idler, Dual Renegade 1
7B500-240 Arbor, S/C Tens Ply, Renegade 1
4FA116-021 Idler Assy, 8-Rib x Ø4.0 Alum 1
2A017-049 Spacer A, SBChev Carb Brkt 5
7PA375-500 Screw, Idler Adjust, 5.00" 1
4PF010-031 Brackt, Idler Adjust Screw 1
7F500-020 1/2-20 Hex Jam Nut GR5 Zinc 1
4FD017-011 Bearing Pilot, 1/2" Bore 1
7A250-077 1/4-20 x .75 Flat Allen GR5 2
7A375-275 3/8-16 x 2-3/4 HXCS G8P Zinc 5
Driver's Side Renegade
Supercharger System
Part No. 4FA218-110/118
PARTS LIST
IMPORTANT: Before beginning installation, verify that all parts are included in the package. Report any
shortages or damaged parts immediately.
vi
®
ENGINEERING, INC.
Part Number Description Quantity Part Number Description Quantity
7C012-020 M12 x 1.75 x 20mm Pltd 3
7J012-092 12mm Washer, Flat 3
4FA111-051 ALT. BRKT ASSY. DSIDE RENEGADE 1
4FP010-011 Bracket, Alternator 1
4FP015-020 Alter.Stay, Lower 1
4FP015-010 Alter.Stay, Upper 1
7A375-100 3/8-16 x 1 G5 HXHD Plt 2
7A312-100 5/16-18 x 1 HXCS GR5P 2
7K375-040 3/8 AN 960 Flat Washr 7
7K312-001 5/16 AN Washer 6
7K437-001 7/16" AN Washer 1
7F375-016 3/8-16 HX Nut 1
7J375-044 3/8 SAE Washer, Pltd 1
7A437-550 7/16 x 5-1/2" Bolt 1
7A375-525 3/8 x 5-1/4 Bolt 2
7A375-325 3/8 x 3-1/4" Bolt 1
4FA017-071 Renegade Brkt Spacer 1
