P/N: 007062

28JAN03 v2.0

(DS Rngde S/C Sys(7062 v2.0))

THIS PRODUCT IS NOT FOR A FIRST TIME VORTECH USER. These products are intended for racing use ONLY by professional
racers/installers. These packages were designed for "off-road" racing use only and are not legal for "public highway" use.
Installation of this package requires a trunk mounted battery and removal of all factory front engine accessories with their related
bracketry.

1986 - 1993

Ford 5.0 Mustang

Driver's Side Renegade Supercharger System

4FA218-110/118

This product is intended for use on healthy, well maintained
racing engines. It is recommended by Vortech that an after-
market (SVO) high strength engine block and cylinder heads
(TFS, Edelbrock, World Products, etc.) be used. An "O-ringed"
cylinder head-to-block seal is also suggested. Installation on
a worn-out or damaged engine is not recommended and may
result in failure of the engine as well as the supercharger.

Before beginning this installation, please read through this
entire instruction booklet and the Vortech Race Super-
charger System Owner's Manual. Other available pieces
designed for use:

2A038-285

Renegade Profile, ø2.85

2A038-300

Renegade Profile, ø3.00

2A038-315

Renegade Profile, ø3.15

(

)

x 3.45 x max. engine rpm = impeller speed

crank pulley diameter

supercharger pulley diameter

To determine the proper supercharger pulley(s), use this
formula:*

Vortech Crank/Supercharger Support Strut:** 4FA110-020
•

Reduces crank snout side-loading. (Places the super-
charger load onto the crankshaft main bearing centerline
and cancels out the load generated by the drive belt
between the crank and supercharger pulleys.)

•

Reduces supercharger input bearing load and wear.

•

Eliminates the possibility of supercharger plate flex.

Refer to the Vortech racing supercharger system owner's
manual for each individual supercharger's specifications.

** Not required for kit function although strongly

recommended by Vortech.

TOOL & SUPPLY REQUIREMENTS
• 3/8" socket and drive set: SAE & metric
• 1/2" socket and drive set: SAE & metric
• 1/2" breaker bar and 4" extension
• 3/8" NPT tap, 3/8-16 tap & handle
• Adjustable wrench
• Open end wrenches: 3/8", 7/16", 1/2", 9/16"

18mm, 19mm

• Center punch and a 5/8" tapered punch

• 5 quarts SF rated quality engine oil
• Oil filter and wrench
• Large screwdriver or pry bar
• Flat #2 screwdriver
• Phillips #2 screwdriver
• Heavy grease
• Silicone sealer
