9a. BATTERY RELOCATION
A. Loosen the power steering lines on
the power steering pump and pivot
them toward the radiator
approximately 2". This will provide
enough clearance for the battery in
its new location. Retighten fittings.
B. Remove the two nut clips from the
original battery tray and attach them
to the provided tray.
C. Using the three existing holes in the
lower plane of the drivers side inner
fenderwell (the previous position of
the air filter assembly), mount the
new battery tray parallel to the head
light assembly. See photo.
D. 1996-1997 models are equipped
with a battery temperature sensor.
This unit must be relocated to the
new battery tray using the supplied
red and black wire extensions.
E. Place the battery on the tray
and secure with the original
retaining parts.
7
NEW TRAY NUT CLIPS
