5.2.2 Setting using wheel circumference

>>> P05

To enter the wheel size manually, you must first
measure the wheel roll circumference on your bike.
Measuring wheel roll circumferences:

step 1

Precisely align valve on the front wheel

vertically to the ground.

Step 2 Mark this spot on the ground with a line
(e.g. chalk).

step 3

Push the bike forwards one turn of the wheel

until the valve is vertical to the ground again.

Step 4 Also mark this spot on the ground.

Step 5 Measure the distance between the two
marks.That is your wheel circumference
(=roll circumference).

Step 6 Enter the wheel circumference measured
in this way into your VDO computer.

ATTENTION: If you have selected KMH display,
you must enter the wheel circumference in mm
(If MPH display is selected, enter the wheel
circumference in inches).

How to set the wheel size manually:

Using

go to SETTINGS/

SELECT. Confirm with

You are now in setting mode
(pressing

for 3 seconds gets

you back to function mode)

Using

go to WHEELSIZE/

SET. Confirm with

MEASUREMENT/KMH.
Confirm with

change to MPH.

WHEELSIZE/BIKE 1.
(use

to go to setting for

bike 2) Confirm with

Using

go to

WHEEL-SIZE/MANUAL SET.
Confirm with

BIKE 1 ...SET SIZE/CONTINUE
Now set the wheel roll circum-
ference measured using

Confirm the entry with

BIKE 1/SET OK? Confirm with

The display confirms: WHEELSIZE/SET DONE.
Automatic return to SETTINGS/SELECT.

How to set the clock:

Using go to SETTINGS/
SELECT. Confirm with

You are now in setting mode
(pressing

for 3 seconds gets

you back to function mode)

Using go to CLOCK/SET.
Confirm with

CLOCK/24-H-MODE (you can
switch to 12-H mode using .
Confirm with

CLOCK...SET HOUR/CONTINUE
Set the hours using .
Confirm the hour setting
with

CLOCK...SET MINUTES/
CONTINUE. Set the minutes
using . Confirm the
minutes setting with

CLOCK/SET OK? Confirm with

The display confirms: CLOCK/SET DONE.
Automatic return to SETTINGS/SELECT.

5.3 Setting the clock

You can program the values on the distance coun-
ter at any time (e.g. at the end of a season).

Using go to SETTINGS/
SELECT. Confirm with

You are now in setting mode
(pressing

for 3 seconds gets

you back to function mode).

5.4 Setting the total kilometres

Using

go to ODOMETER/

SET. Confirm with

Attention: The factory settings for bike 1 = 2155
mm and for bike 2 = 2000 mm. If you do not enter
any wheel sizes, the computer works with these

factory settings. The values measured in this
way for speed, distance etc. can differ widely
from the actual values.
