Drive carrier interface panel – StorCase Technology 12-Bay 4U SCSI Ultra320 User Manual
Page 18
User Interface
9
InfoStation 12-Bay SCSI User's Guide - Rev. B00
StorCase Technology, Inc.
The Drive Carrier Interface consists of the following indicators:
Table 1: Drive Carrier Interface Components
Figure 5: InfoStation Drive Carrier Interface
Drive Carrier Interface Panel
Each InfoStation drive carrier provides a User interface for individual carrier operation.
Drive
Ready
Drive
Activity
Drive
Fault
Key
Lock
Carrier
Handle
IFS14_3
LEDs
Drive Ready LED
Drive Fault LED
Steady glow indicates that drive is inserted
and ready for access.
Steady glow indicates drive failure.
Steady glow indicates drive is being accessed.
Drive Activity LED
