DS550 User's Guide - Rev. A04 StorCase Technology, Inc.
Appendix A - Specifications/Dimensions 19
Figure A-2: DS550 Rack Mount Physical Dimensions
(Dimensions are for reference only)
Figure A-1: DS550 Tower Physical Dimensions
(Dimensions are for reference only)
1.75
(44.5mm)
Top View
Front View
Right Side View
(Mounting Holes for Optional Slide Rail Kit)
6.98
(177.3mm)
6.00
(152.4mm)
4.25
(108.0mm)
7.75
(196.9mm)
0.20
(5.1mm)
1.17
(29.7mm)
8.06
(204.7mm)
23.87
(606.3mm)
4.58
(116.3mm)
15.36
(390.1mm)
13.04
(331.2mm)
16.92
(429.8mm)
19.00
(482.6mm)
2.62
(66.5mm)
1.66
(42.2mm)
550_18
