StorCase Technology DS550 User Manual
Page 15
DS550 User's Guide - Rev. A04
StorCase Technology, Inc.
Introduction
7
Figure 4: DS550 Rear Panel
Power Cord
Retainer Clip
A/C Power In
I/O Panel
(6 Total)
Blower Speed
Selector Switch
400W Power
Supply Module
Module
Handle
A/C Power
Switch
Power Supply
Module Status
LED
Captive
Screw
Logic Card
Blower
Vent
Factory-Reserved
550_4
Factory-Reserved - Allows the installation of future StorCase upgrade products.
Logic Card - Allows easy access to the DS550 hot-pluggable daughterboard (refer
to Appendix B for further information).
