StorCase Technology DS400 User Manual
Page 22
Installation
13
DS400 User's Guide - Rev. E01
StorCase Technology, Inc.
DS400
Back Panel
0583
Device 1
Device 2
Device 3
Device 4 (Empty Bay)
Device 6
Device 7
Device 8
Device 9
Pin 1
Device 5 (Empty Bay)
Channel 1
(2 Devices)
Channel 2
(1 Device)
Channel 3
(4 Devices)
NOTE:
Internal wiring must be ordered separately [available with 50-pin MM (HD50),
68-pin HD, or 68-pin VHDCI rear panel connectors].
Figure 11: Typical Internal SCSI Cable Configuration
