12 Installation
StorCase Technology, Inc. DS400 User's Guide - Rev. E01
5. Reinstall the filler panel(s) that were removed earlier (fixed media devices only). Check
the clearance between the newly installed drive(s) and the filler panel(s). If installing
removable media devices, verify that the installed devices are flush with the DS400
front panel.
6. Tighten the drive mounting screws.
7. Connect the I/O cable(s) to the drive(s). Verify that the Pin 1 indicator on the cable is
properly aligned (Figure 11). Refer to the drive manufacturer's documentation for
specific drive information. StorCase offers several internal SCSI cable configurations
for the DS400 (refer to Appendix B for available internal SCSI device connections).
8. Connect the 4-pin DC power cable(s) from the device to the Data Silo power strip
(Figure 10).
9. Reinstall the Data Silo cover and fasten all screws.
10. Connect the external AC power cable to the Data Silo.
