StorCase Technology DE100i-A - Manual (Page 10)

DE100i-A User's Guide - Rev. F01 StorCase Technology, Inc.
Introduction 3
Figure 2: DE100i-A Receiving Frame and Carrier
This User's Guide describes the steps required to install the StorCase Data Express
DE100i-A removable enclosure inside a computer peripheral bay. This guide supplements
documentation provided with the host computer system, operating system, and the drive to
be installed within the Data Express carrier.
General Description
The StorCase Technology Data Express ® DE100i-A is a removable lightweight drive carrier
and receiving frame designed to provide durable and reliable mounting for 3.5” AT/IDE drives
within 5.25" half-height peripheral slots (Figure 2).
The DE100i-A allows a drive to be removed and transported to another DE100i-A-equipped
computer or expansion chassis, and also provides the ability to secure sensitive data by
removing and storing the drive safely for future use.
Drive Carrier
0425
Receiving
Frame
