10 Installation
StorCase Technology, Inc. DE110 for Backup User's Guide - Rev. A04
Installing the Receiving Frame
NOTES: Use a #2 Phillips screwdriver for this procedure.
Refer to your system motherboard manufacturer's documentation for further
information.
The drive should be installed into the carrier before installing the receiving frame into the
mounting bay of a computer or expansion chassis.
1. Turn OFF power to the computer.
2. Open the computer system according to the manufacturer’s instructions. If neces-
sary, temporarily remove any expansion boards that may make installation difficult.
3. Locate the USB connector(s) on the system motherboard (refer to your system
motherboard manufacturer's documentation for further information).
Depending on your system motherboard, it may have one or more 9-Pin USB con-
nectors (with one typically connected to front USB ports on the PC), or it may have
only a 4-Pin USB connector.
If your system motherboard has several 9-Pin USB connectors, proceed to Step 4.
If your system motherboard has only one 9-Pin USB connector, proceed to Step 5.
If your system motherboard has only a spare 4-Pin USB connector (instead of
9-Pin), proceed to Step 6.
4. Locate a spare 9-Pin USB connector on the system motherboard and connect the
female connector on the split USB cable (provided) to it (Figures 8 & 11).
