8 Installation
StorCase Technology, Inc. DE110 for Backup User's Guide - Rev. A04
INSTALLATION
Preparation
While performing the steps in this section, work on a soft surface to prevent excessive shock
to the drive being installed. Also refer to the manufacturer's documentation provided with the
drive.
•
Remove the drive from its protective packaging.
•
Plastic Drive Bezel: If the drive came equipped with a plastic front bezel, it must be
removed before installing the drive into the drive carrier.
•
Master/Slave Drive Selection - Drive can be configured as Cable Select (recommended)
or as Master.
Drive Installation
NOTE: A #2 Phillips screwdriver will be required during this procedure.
1. Attach the DC power cable (from the Drive Carrier Board) to the drive (Figure 6).
2. Carefully insert the drive into the carrier. Slide the drive towards the Drive Carrier
Board, so that the I/O connector on the drive mates with the connector on the Drive
Carrier Board (Figure 6). Make sure that the DC power cable is not pinched.
Turn the drive/carrier assembly over.
3. Fasten the drive into place with four (4) #6-32 Phillips Flat Hd. screws (Figure 6).
Some drives may require minor adjustment before securing into carrier with screws.
4. Install the provided drive cover (Figure 7).
