StorCase Technology DE50 User Manual
Page 18
PATA DE50 User's Guide - Rev. E00
StorCase Technology, Inc.
Installation
11
6.
Carefully insert the drive/bracket assembly into the top cover and secure with four
(4) M3 screws (saved from Step 1) as shown in Figure 6.
Figure 10: Drive Mounting Bracket Installation
M3 Phillips
Flat Hd. Screw
(4 Total)
Circuit
Board
NOTE: Make sure the circuit board is
properly seated in the bracket
slot before securing drive to the
bracket assembly.
Front
