5.10 DescriptionofControls
5 THE PRO-CODEC PLUG-IN
CODEC
When selected, will route the encoded-decoded signal to the output.
DIFF
When selected will route the difference signal to the output. The difference signal is
the encoded-decoded signal subtracted from the unprocessed input signal.
MASTER IN
With the
IN button selected, all processing is active. If not selected, the outputs are
disabled. However, much of the processing remains active, for example, the FFT
display and the overload detection. The
MASTER IN control is automatable.
The five
MON buttons and the MASTER IN, CODEC and DIFF buttons all provide
smoothly interpolated and glitch-free audio switching. It is advisable to use these for
auditioning, rather than using the host application’s bypass function (which is commonly
not interpolated).
BitstreamLevels/TrimTab
Trim Tab
METERS (x5)
Indicate when a decoded
signal is above 0 dB. Includes peak hold.
MAX dB (x5)
Indicates the maximum
level detected by the decoder. This value is
white if negative, and red if positive. Clicking
in this window resets the peak hold value.
TRIM (x5)
Indicates the input trim to the individual
codecs. This is a Touch Pad control, allowing a fader style movement to determine
an attenuation of up to a maximum of 12 dB. If this value is non-zero, the trim value
is displayed darker. The TRIM dB controls can be automated.
