5.10 DescriptionofControls
5 THE PRO-CODEC PLUG-IN
InputSection
Input Section
SIGNAL
The input meter
indicates 2 dB per LED below -12dBFs, and
0.5dB per LED above -12dBFs. It includes
peak-hold indication. The meter will be mono,
stereo or multi-channel depending on context.
CH.MAP (5.1instancesonly)
Use these options
to match the input/output channel mapping
of the plug-in to the channel mapping
used in your host DAW. If you use SMPTE/ITU
channel order, simply select this option.
ManagerButton
Click the Manager icon button to open the
Manager application for offline encoding,
decoding and metadata editing.
FFT DisplaySection
L/R/Sum/etc
Select which channel’s FFT to display.
FFT/LISS
Switch the display between FFT and Lissajous.
NMR
Hide/Show the NMR indicator line on the FFT
Log/Lin
Switch the FFT frequency axis between a logarithmic and linear scale.
ResetZoom
Reset the zoom level of the FFT frequency and amplitude scales to default.
