PARTS LIST FOR SZEA3000 AND SZEA6000 SERIES COMPRESSION RIVETER
– “C” YOKE STYLE
SERIAL “A”
TABLE 1—SET HOLDER DIMENSIONS
PART NO.
A
B
C
D
E
F
G
H
J
E1090
1 1/2” 1 1/4” 3/8”
3/16” 1 7/8” 3 3/8” 2 7/8” 9/16”
7/32”
E1122
1 1/2” 1 1/4” 7/16”
1/4”
1 7/8” 3 3/8” 2 7/8” 11/16”
1/4”
C’ YOKE DIMENSIONS
PART NO.
DIA.
LENGTH
SET HOLE
E1103 3/8” 2
9/16”
3/16”
E1105 3/8” 2
9/16”
1/4”
