350P Preamplifier
____________________________________________________________________________________
18
Specifications (cont’d)
Optional Digital-to-Analog Converter:
Digital Input Types ......................................... S/PDIF (RCA) x 2 USB x 1 TosLink x 1
Digital Input Impedance (S/PDIF) ................... 75 ohms @ 0.5 Volts
DAC / Digital Filter .......................................... BurrBrown PCM1793
Bit-depth range ............................................. 16 - 24 bits
Sampling Frequency Rates ............................... 44.1, 48, 88.2, 96, 176.4 and 192kHz
Frequency Response (audible) ........................ 20Hz - 20kHz +0/-0.2dB
Frequency Response (full range) ................... 2Hz - 72kHz +0/-3dB
THD @ 1kHz, 0dBFS (A-weighted) ................. < 0.001 %
IMD ............................................................. < 0.004 %
Dynamic Range ............................................. > 116dB
Signal-to-noise ratio ...................................... > 115dB @ full output
Slew Rate ..................................................... 50V/µs
Channel Separation ....................................... > 115dB
Low Level Linearity ........................................ ±1.0dB to below 120dBFS
Intrinsic Jitter ............................................... < 25 picoseconds
RMS
Balanced Pin Assignment:
Pin
1........................... Ground
Pin 2........................... Positive
Pin 3 .......................... Negative
12 Volt Trigger: Logic........................... Direct (0V off, 12V on)
Jack............................
3.5mm microphone jack
Input Impedance ......... 1k Ω
Current Consumption ... 12mA
NOTE: If you require the RS-232 codes for your Nēo 350P, please visit the "Contact Us" page
and complete the "Information request" form on our website at www.simaudio.com.
Fuse Replacement:
For the 120V version use a 0.2A fast blow (5 x 20mm size).
For the 230V version use a 0.1A fast blow (5 x 20mm size).
