350P Preamplifier
____________________________________________________________________________________
17
Specifications
Configuration ................................................ Fully balanced differential, stereo
Power Supply Transformers ............................. 1 x 10VA (audio); 1 x 10VA (controller)
Power Supply Capacitance ............................. 26,400µF
Balanced inputs (XLR) .................................. 2 pairs
Single-ended inputs (RCA) ............................ 4 pairs
Mini-jack input ............................................... 1 (1/8”)
Monitor Loop (RCA) ........................................ 1
Input Impedance .......................................... 22,000
Ω
Input Sensitivity ............................................ 200mV – 5.0V RMS
Headphone output........................................... 1 ( 1/4” Stereo TRS)
Balanced outputs (XLR) ................................. 1 pair
Single-ended outputs (RCA) ........................... 2 pairs (fixed and variable)
Output Impedance ......................................... 100
Ω
Gain .............................................................. 6dB
Signal-to-noise Ratio (20Hz-20kHz) ................. 120dB @ full output
Maximum Output Voltage (Balanced) ............... 16 Volts
Maximum Output Voltage (Single-Ended) ......... 8 Volts
Audible Frequency Response .......................... 20Hz - 20kHz ±0.1dB
Full-Range Frequency Response ..................... 5Hz - 100kHz +0/-3.0dB
Crosstalk @ 1kHz .......................................... -96dB
Intermodulation Distortion ............................. Unmeasureable
THD (20Hz - 20kHz) ..................................... < 0.0005%
Remote Control ............................................. Full-Function (CRM-2)
Power Consumption @ idle ............................. 12.5 Watts
AC Power Requirements ................................. 120V / 60Hz or 240V / 50Hz
Shipping Weight ............................................ 16.5 lbs / 7.5 Kgs
Dimensions (W x H x D, inches) ..................... 16.88 x 3.5 x 13.1
Optional Phono Section:
Input Impedance .......................................... Adjustable - 100 ohms and 47K ohms
Input Capacitance ......................................... Adjustable - 0pF and 100pF
Gain ............................................................. Adjustable 40dB and 60dB
Input overload @ 40dB gain ............................ 58mV RMS
Input overload @ 60dB gain ............................ 3mV RMS
Signal-to-noise Ratio (full scale @ 40dB gain) ... 107dBr
Signal-to-noise Ratio (full scale @ 60dB gain) ... 85dBr
Frequency Response ....................................... 20Hz - 20kHz (±0.5dB)
Crosstalk @ 1kHz ............................................ -97dB
IMD .............................................................. < 0.009%
THD (20Hz - 20kHz) ....................................... < 0.001%
