4848B Reactor Controller
w w w . p a r r i n s t . c o m 25
Operation Mode
Press to advance
Use key to set temperature set point
Control setting RUN or STOP
Start pattern setting
(PID program control and
Time setting)
Decimal point position selection
(except for B, S, R type inputs, all the other types can be set)
Upper-limit alarm 1
(This parameter is available only when ALA1 function is enabled)
Lower-limit alarm 1
(This parameter is available only when ALA1 function is enabled)
Upper-limit alarm 2
(This parameter is available only when ALA2 function is enabled)
Lower-limit alarm 2
(This parameter is available only when ALA2 function is enabled)
Upper-limit alarm 3
(This parameter is available only when ALA3 function is enabled)
Lower-limit alarm 3
(This parameter is available only when ALA3 function is enabled)
Setting lock mode
Display output value of 1st output group
Display output value of 2nd output group
