Motor Controller
w w w . p a r r i n s t . c o m 9
Fuse Rating Part number
Instrument
Fuse Fast acting, 1
Amp, 250VAC 139E6
Main Fuse(s) Fast acting, 10
Amp, 250VAC 185E2
Motor fuse /
reset check back
panel for speci-
fi cations check part list
Motor Board
Fuse (A+) Very Fast act-
ing, 8 Amp,
250VAC 959E5
Motor Board
Fuse (L) Fast acting, 10
Amp, 250VAC 185E2
Caution!
Unplug unit before servicing. For
continued protection against possible
hazard, replace fuses with same type
and rating of fuse.
Access to the Controller Cabinet
To open the controller cabinet, unplug the power
cord and remove the four screws on the sides of the
top panel. Then lift the top panel off, providing full
access to all internal components.
Caution!
Inside of controller cabinet should be
accessed by qualifi ed personnel only.
Fuses
The A2110E Controller has a number of fuses which
are intended to be fi eld serviceable. The instrument
fuse is only provided if there is a digital display me-
ter installed.
