5400 Tubular Reactor System
P a r r I n s t r u m e n t C o m p a n y 4
Explanation of Symbols
II On position, full power heater switch
I On position, half power heater switch
O Off Position
~ Alternating Current (AC)
This CAUTION symbol may be present on the Product Instrumentation
and literature. If present on the product, the user must consult the ap-
propriate part of the accompanying product literature for more infor-
mation.
This CAUTION symbol indicates that the surface may be hot.
Protective Earth (PE) terminal. Provided for connection of the Protec-
tive Earth (green or green/yellow) supply system conductor.
Intended Usage
This system has been designed for use as a high
pressure reactor system. It has been designed, built,
and tested to strict physical and electrical standards.
However, it is the user’s responsibility to install
and operate it in conformance with local pressure
and electrical codes. If this equipment is used in a
manner beyond its intended usage, the protection
provided by the equipment may be impaired.
Environmental Conditions
This instrument is intended to be used indoors.
Caution!
Do not use in hazardous atmospheres.
Operating: 15 ºC to 35 ºC; maximum relative humid-
ity of 80% non-condensing. Installation Category II
(over voltage) in accordance with IEC 664.
Pollution degree 2 in accordance with IEC 664.
Altitude Limit: 2,000 meters.
Storage: -25 °C and 65 °C; 10% to 85% relative
humidity.
Provisions for Lifting and Carrying
The 5400 Tubular Reactor System and its compo-
nents are very heavy. Before moving ensure all
cables are disconnected. Use proper and safe lifting
techniques when installing or moving the 5400 Tubu-
lar Reactor System and/ or its components.
Unpack Carefully
Unpack the equipment carefully and check all the
parts against the packing list. Ensure that all layers
of the foam packing are inspected and verify that
all components have been removed before pack-
ing materials are discarded. If shipping damage is
discovered, report it immediately to the delivering
carriers. The reactor, cart, gas feed system, liquid
feed system, product handling equipment and con-
trollers may be packaged separately for convenience
in shipping, but these parts are easily reassembled.
Examine the components closely for any loose parts
or shipping damage and be sure to check all layers
of packing materials thoroughly so as not to over-
look any parts which might otherwise be discarded.
General Assembly
Although all tubular reactor systems are custom
built to the customer’s needs, the general assembly
is typical for each unit. The general assembly con-
sists of mounting the gas feed rack and the reactor/
