5400 Tubular Reactor System
w w w . p a r r i n s t . c o m 13
1/4NPT
REF
HEAD
3491HC
DROP BAND ASSY
2X A3511HC
33HDF3 BOLTS
EACH WITH 6X
COMPRESSION RING
2X 430HC
HEAD
3489HC
SPLIT RING ASS'Y
2X A3487HC2
(GRAPHITE)
SECTION A-A
1/8NPT REF
429HC2KF
2X 429HC2
PTFE GASKET
3540HC/HC2/HC3
CYLINDER
(3540HC)
32.38 (3540HC2)
44.38 (3540HC3)
1.437
20.38
2.975
24.30 (W/3540HC)
36.30 (W/3540HC2)
48.30 (W/3540HC3)
2X
2X 1.875
18.37 (3540HC
30.37 (3540HC2)
42.37 (3540HC3)
5404 Tubular Reactor Assembly
Internal View
5404 Cylinder Guide
Cylinder Part No. Total Volume Heated Length Heated Volume
3540HC 550 mL 12 in 350 mL
3540HC2 850 mL 24 in 700 mL
3540HC3 1150 mL 36 in 1000 mL
3X 1/16NPT REF
456HCF2 BOLT REF
(DROP BAND)
A
A
3491HC Head
Top View
3489HC Head
Bottom View
