Mini Bench Top Reactors
P a r r I n s t r u m e n t C o m p a n y 24
External Fittings
Part No. Description
A888HC2 Rupture disc assembly
49HC2 Orifice cone
527HC Orifice ring
433HC4 Safety head outlet
A544VBKL Valve, Straight 1/8” NPTF
A544VB2KL Valve, Angled 1/8” NPTF
280VBAD Nipple, 1/8” NPTM
A92HWAD Male Connector 1/8 NPTMx1/4T
(T316SS for top of cooling loop)
35HC Compression Nut
40HC Bushing
1452HC5 Gage Adapter
1452HC6 Valve Adapter
302VBAD Female Conn, 38” Tube – 1/4” NPTF
1446HC2 Adapter, ‘A’ Cone F – 1/8” NPTM
424HC2 Anti-Seize Lubricant
79HW* Plug, Hex Head 1/8” NPTM
94CAAD Plug, Hex Head 1/4” NPTM
Thermocouple/Thermowell
Part No. Description Code
A472E Thermocouple, Grounded
300mL Type J, 7-1/2 TC
A472E2 Thermocouple, Grounded
450mL Type J, 9-1/2 TC
A472E3 Thermocouple, Grounded
600mL Type J, 11-1/2 TC
A472E4 Thermocouple, Grounded
100/160mL Type J, 5-1/2 TC
A490E Thermocouple, Dual
Grounded, 7-1/2, 1/8”OD TC
A490E2 Thermocouple, Dual
Grounded 9-1/2 TC
A490E3 Thermocouple, Dual
Grounded 11-1/2 TC
3366HC Nut, 1/8” Tube Seal TC
3367HC Ferrule, 1/8” Tube Seal TC
1360HC Ferrule SS, 1/4” Tube Seal TW
1359HC Nut, 1/4” T Seal TW
A1453HC Thermowell, 1/4” OD
Specify volume & head style (fi xed or movable)
Rupture Disc Assembly
See manual 231M for a full list of safety rupture discs.
* For Special Fittings
