Page 27

w w w . p a r r i n s t . c o m
5100 Low Pressure Reactors
27
IMPELLER
832HC35
SHAFT, STIRRER
2630HC4
NOT SHOWN:
A2735HC SPLIT RING ASSY
A472E THERMOCOUPLE
A1453HC
MALE CONNECTOR (REF)
A138CA
HEAD
2635HC3
MALE CONNECTOR
A92HW
A837HC
METAL CYLINDER 160mL
DIP TUBE
822HC33
2632HC SERIES O-RING
2943HC4HZ = PTFE COATED
THERMOWELL
IMPELLER
A1453HC
A837HC
2630HC14
METAL JACKETED
CYLINDER, 215mL
MALE CONNECTOR (REF)
A138CA
HEAD
2635HC3
MALE CONNECTOR
A92HW
THERMOWELL
SHAFT, STIRRER
832HC36
822HC44
2943HC5HZ = PTFE COATED
DIP TUBE
NOT SHOWN:
A2735HC SPLIT RING ASSY
2632HC SERIES O-RING
A472E THERMOCOUPLE
5100 Metal Vessels Internals
160 mL - 215 mL Vessels
