P a r r I n s t r u m e n t C o m p a n y
5100 Low Pressure Reactors
26
686HC20 DIP TUBE (1.5L)
2930HC3 COOLING LOOP (1.0L)
A472E3 THERMOCOUPLE (1.5L)
A1404HC3HZ = PTFE COATED
265HC27 THERMOWELL (1.5L)
48HC SERIES GASKET
2930HC4 COOLING LOOP (1.5L)
A2916HC SPLIT RING ASSY (FOR GLASS)
(3) A92HW
NOT SHOWN:
265HC7 THERMOWELL (1.0L)
A449HC STIRRER SHAFT ASSY (1.0L)
A449HC22 STIRRER SHAFT ASSY (1.5L)
A2912HC SPLIT RING ASSY (FOR METAL)
2913HC SERIES O-RING
2915HC2 HEAD
A472E2 THERMOCOUPLE (1.0L)
MALE CONNECTOR
686HC19 DIP TUBE (1.0L)
(2) A358HC5 PROPELLER ASSY
METAL CYLINDER (REF)
GLASS CYLINDER (SHOWN)
2825HC SERIES
2910HC SERIES
A1404HC2 STIRRER BRACKET ASSY
5111 & 5112 Internals
1 L & 1.5 L Glass Vessels
