5100 low pressure reactors – Parr Instrument Series 5100 User Manual
Page 24
P a r r I n s t r u m e n t C o m p a n y
5100 Low Pressure Reactors
24
SHAFT, STIRRER
(3) A92HW
MALE CONNECTOR
THERMOWELL
A1453HC
822HC32
5103 600mL
COOLING LOOP
831HC8
PTFE COATED =
1218HC5HZ INNER BRACKET
1219HC5HZ OUTER BRACKET
1260HCFHZ SCREW
A2526HC SPLIT RING ASSY (GLASS)
NOT SHOWN / COMMON FOR ALL
2632HC SERIES O-RING
A2735HC SPLIT RING ASSY (METAL)
MALE CONNECTOR (REF)
A138CA
STIRRER BRACKET ASSY
IMPELLER
A472E3
THERMOCOUPLE (NOT SHOWN)
832HC33
(2) A837HC
DIP TUBE
HEAD
2635HC3
2943HC3HZ
THERMOWELL, PTFE COATED
A1260HC2
5100 Internals (continued)
600 mL Glass Vessels
