P a r r I n s t r u m e n t C o m p a n y
5100 Low Pressure Reactors
14
Heads*
Part No. Description
2635HC3 Head for 160 mL - 600 mL
2635HC4 Head for 160 mL - 600 mL,
footless mag drive
2915HC2 Head for 1000 mL - 1500 mL
2915HC3 Head for 1000 mL - 1500 mL,
footless mag drive
Internal Fittings*
Thermowell and Thermocouple*
Part No. Description
For 160 mL - 600 mL:
217VBAD
Replacement nut for thermowell
218VBAD Replacement ferrule set for thermowell
A1453HC Thermowell, 1/4" OD, T316, 12" L
(cut to length)
Part No. Description
2943HCHZ Thermowell, 300 mL, PTFE coated
T316, 6.86" length
2943HC2HZ Thermowell, 450 mL, PTFE coated
T316, 8.86" length
2943HC3HZ Thermowell, 600 mL, PTFE coated
T316, 10.86" length
2943HC4HZ Thermowell, 160 mL, PTFE coated
T316, 4.73" length
2943HC5HZ Thermowell, 215 mL, PTFE coated
T316, 5.43" length
A472E Thermocouple, type-J, 7 ½”, grounded
A472E2 Thermocouple, type-J, 9 ½”, grounded
A472E3 Thermocouple, type-J, 11 ½”, grounded
A472E4 Thermocouple, type-J, 5 ½”, grounded
A490E Dual thermocouple, type-J, 7 ½”
A490E2 Dual thermocouple, type-J, 9 ½”
A490E3 Dual thermocouple, type-J, 11 ½”
Cylinders*
Model No. Size Material Plain Jacketed
5101
300 mL Glass 2525HC 2525HC11
300 mL Metal 2630HC 2630HC11
5102
450 mL Glass 2525HC2 2525HC12
450 mL Metal 2630HC2 2630HC12
5103
600 mL Glass 2525HC3 2525HC13
600 mL Metal 2630HC3 2630HC13
5104
160 mL / 215 mL Glass 2525HC4 (160 mL) 2525HC14 (215 mL)
160 mL / 215 mL Metal 2630HC4 (160 mL) 2630HC14 (215 mL)
5111
1000 mL Glass 2825HC 2825HC11
1000 mL Metal 2910HC3 2910HC13
5112
1500 mL Glass 2825HC2 2825HC12
1500 mL Metal 2910HC4 2910HC14
Parts List
*Note: Special material internal parts (not T316) will have a suffix designating the material:
CH - Alloy C-276 CA - Titanium CB - Alloy Cb-20
CG - Alloy B-2 CX - Zirconium HZ - PTFE coated T316
(I.e.- a 300 mL Alloy C-276 dip tube would be 832HC31CH)
Thermowell and Thermocouple (Continued)
