Transmitter and receiver binding, Transmitter control identification – ParkZone PKZ3600 User Manual

Page 6

The P-51D RTF comes pre-bound to the included transmitter. If you should

need to re-bind your P-51D follow the simple directions below.

1. To bind your P-51D, first plug the flight battery into the airplane.

2. When you see the LED on the receiver begin to flash while looking

through the opening at the front of the P-51D under the spinner, push

the left stick of the transmitter inward into the case (NOT pulling down

on throttle stick) until you hear it click.

3. While pushing the stick in, power on the transmitter, release stick once

the transmitter is powered on. The transmitter will beep and the LED on

the face of the transmitter will pulse.

4. Once the transmitter stops beeping it will take a second or two to con-

nect with the airplane.

The transmitter is now bound to the airplane. If you encounter any problems,

repeat the binding process again, see the troubleshooting guide or call the

Horizon Support Team at 1-877-504-0233.

Note: We strongly recommend setting the transmitter on low rate

for the initial flights. To set transmitter to low rate, while

the transmitter and airplane are powered on, push the right

stick inward until you hear it click. The LED on the transmit-

ter face will be flashing steadily indicating that the transmit-

ter is in low rate. To set the transmitter back to high rate

push the right stick inward until you hear it click and the

LED on the transmitter face is solid red.

Transmitter and Receiver Binding

Mode 1

Mode 2

Rudder Trim

Rudder/Throttle

Functions

Rudder/Elevator

Functions

Aileron/Elevator

Functions

Aileron/Throttle

Functions

Throttle Trim

Elevator Trim

Throttle Trim

Aileron Trim

Transmitter Control Identification
