2.0 - Device Specification - General
The following figures and tables summarize specifications of the TSS-series product.
TAbLE 2.1 –GENERAL EqUIpmENT SpECIFICATIONS
Feature SPecIFIcatIon
Dimensions Refer to Figures 2.1 and 2.2, as well as Tables 2.3 and 2.4
Weight, in lbs (kg) Refer to Tables 2.3 and 2.4
Rated input 2A, 2.25Ω (only to be operated by Nor-Cal Products’ controller models)
Actuation Speed 2 sec open to closed for 2.5” – 6” valves 4 sec open to closed for 8” and 10” valves
Position Resolution 1:6,144,000 steps for 2.5” – 6” valves. 1:12,288,000 steps for 8” and 10” valves.
Leak Rate 1x10 -9 atm • scc/sec He (for valves with Viton® seals)
Allowable Gate Differential Pressure 15 psi (103.4 kPa)
Heating Capabilities Body can be heated up to 305ºF (150ºC) with optional heater kits.
Protection Class i
Degree of Protection (iP) X0
Laser Class 1 (LED’s)
Certifications CE Standard for Process Equipment including EMC Directive 89/336/EC and Machinery Directive 89/392/EEC
Maximum Altitude 6562 ft (2000 m)
Allowable Ambient Operating Temperature 32ºF – 122ºF (0ºC - 50ºC)
Allowable Ambient Humidity 0 – 95% non-condensing
TAbLE 2.2 – TSS RELIAbILITy
SPecIFIcatIon commentS
* MTBF > 2 million cycles or > 11,500 hours
Processes with large amounts of effluent contamination or highly aggressive chemistries may reduce the MTBF
due to condensation on moving parts and/or O-ring degradation.
* Warranty 1 year
installation Clearance
For iQ-series TSSs 3” (75 mm) is required on all perforated sides. Otherwise, a minimum of 3 ½” (90 mm) is
needed on top to allow for connector(s).
