Throttling Gate Valves with IqA or IqD Control module
Size
Family
Flange type
Flange
Size
o-ring option
2
250 iSO 63 Viton (leave blank)
300 iSO 80 Perlast G74P (enter PP7)
400 iSO 100
600 iSO 160
800 iSO 200
1000 iSO 250
250 CF or CFM 450
400 CF or CFM 600
600 CF or CFM 800
800 CF or CFM 1000
1000 CF or CFM 1200
Standard Throttling Gate Valves (to be operated by a stand-alone ApC-series controller)
AppENDIx III - Valve, Accessories and Cable Assembly Ordering Information
tSS- IqX
1 _ _ _ _ _ _ _ _ _ _
Size
Family
Flange type
Flange
Size
o-ring option
2
250 iSO 63 Viton (leave blank)
300 iSO 80 Perlast G74P (enter PP7)
400 iSO 100
600 iSO 160
800 iSO 200
1000 iSO 250
250 CF or CFM 450
400 CF or CFM 600
600 CF or CFM 800
800 CF or CFM 1000
1000 CF or CFM 1200
tSS
_ _ _ _ _ _ _ _ _ _
2
NOTE: Other O-ring materials are available. Call Nor-Cal intellisys Customer Support for details
1
NOTE: “X” refers to the communications mode. D = DeviceNet, A = analog, etc…
