5.2 - Spare parts and Kits Ordering Information
TAbLE 5.2 – SpARE pARTS AND KITS ORDERING INFORmATION
Ref.
No.
Description DN-63 DN-80 DN-100 DN-160 DN-200 DN-250
1
Bonnet bolt/washer set (one each of
M8x1.25x20 SHCS SS plus M8 Schnorr
lock washer)
TSS-BBW
(Total of 10
needed for com-
plete valve)
TSS-BBW
(Total of 12
needed for com-
plete valve)
TSS-BBW
(Total of 12
needed for com-
plete valve)
TSS-BBW
(Total of 20
needed for com-
plete valve)
TSS-BBW
(Total of 22
needed for com-
plete valve)
TSS-BBW
(Total of 28
needed for com-
plete valve)
2 bonnet cover with Viton® o-ring TSS-63-911A TSS-80-911A TSS-100-911A TSS-160-911A TSS-200-911A TSS-250-911A
3 Oldham coupling center disk 54-310-004 54-310-004 54-310-004 54-310-004 54-310-004 54-310-004
3A
Oldham hub and key for mounting to
gear box
TSS-Hk-gb TSS-Hk-gb TSS-Hk-gb TSS-Hk-gb TSS-Hk-gb TSS-Hk-gb
3b
Oldham hub and key for mounting
to motor
TSS-Hk-M TSS-Hk-M TSS-Hk-M TSS-Hk-M TSS-Hk-M TSS-Hk-M
4*
Rotary disk indicator assembly (disk
& screw)
TSS-63-966A TSS-80-966A TSS-100-966A TSS-160-966A TSS-200-966A TSS-250-966A
5* Shaft key TSS-63-962A TSS-80-962A TSS-100-962A TSS-160-962A TSS-200-962A TSS-250-962A
6* Shaft TSS-63-968A TSS-80-968A TSS-100-968A TSS-160-968A TSS-200-968A TSS-250-968A
7 Rotary Seal – Viton® TSS-63-961 TSS-80-961 TSS-100-961 TSS-160-961 TSS-200-961 TSS-250-961
8
gate and carriage assembly with
bonded Viton® seal
TSS-63-925 TSS-80-925 TSS-100-925 TSS-160-925 TSS-200-925 TSS-250-925
8A
gate and carriage assembly with
replaceable Viton® seal
TSS-63-925A TSS-80-925A TSS-100-925A TSS-160-925A TSS-200-925A TSS-250-925A
8b
gate (only) with replaceable Viton
seal
TSS-63-925b TSS-80-925b TSS-100-925b TSS-160-925b TSS-200-925b TSS-250-925b
8C gate O-ring Seal - Viton OR-2-232V OR-2-235V OR-2-241V OR-2-434V OR-2-444V OR-2-450V
9 gear box w/Oldham hub and key TSS-gb1 TSS-gb1 TSS-gb2 TSS-gb3 TSS-gb4 TSS-gb5
10
Motor Assembly w/Oldham hub and
motor mount (standard)
TSS00-001 TSS00-001 TSS00-001 TSS00-001 TSS00-001 TSS00-001
10A Motor Assembly w/Oldham hub (IQA) TSSIQA-001 TSSIQA-001 TSSIQA-001 TSSIQA-001 TSSIQA-001 TSSIQA-001
10b Motor Assembly w/Oldham hub (IQD) TSSIQD-001 TSSIQD-001 TSSIQD-001 TSSIQD-001 TSSIQD-001 TSSIQD-001
11
IQ-drive motor mount (used to
change standard valve to IQ-type)
TSS-XIQ-MM TSS-XIQ-MM TSS-XIQ-MM TSS-XIQ-MM TSS-XIQ-MM TSS-XIQ-MM
12
bearing kit (includes bearing and
replacement Circlip)
TSS-63-Sb TSS-80-Sb TSS-100-Sb TSS-160-Sb TSS-200-Sb TSS-250-Sb
N/A
Shaft assembly removal tool. Helps
remove the shaft and bearing during
O-ring and valve maintenance
SD-M0014 SD-M0014 SD-M0014 SD-M0014 SD-M0014 SD-M0014
*NOTE: Effective May 2005, the Rotary disc indicator, shaft and shaft key designs changed. TSS valves are serialized using a date code followed
by a three-digit sequential number. The serial number format are the letters SS followed by the digits YYMMxxx, where YY is the year, MM is
the month and xxx is the sequential number. Please refer to Table 5.2A below for replacement parts for valves manufactured before this date.
TAbLE 5.2A – SpARE pARTS AND KITS ORDERING INFORmATION FOR VALVES mADE pRIOR TO mAy 2005
Ref.
No.
Description DN-63 DN-80 DN-100 DN-160 DN-200 DN-250
4
Rotary disk indicator
assembly (disk, spacer &
screw)
TSS-63-966 TSS-80-966 TSS-100-966 TSS-160-966 TSS-200-966 TSS-250-966
5 Shaft key TSS-63-962 TSS-80-962 TSS-100-962 TSS-160-962 TSS-200-962 TSS-250-962
6 Shaft TSS-63-968 TSS-80-968 TSS-100-968 TSS-160-968 TSS-200-968 TSS-250-968
