Page 179
Vigor2130 Series User’s Guide
171
Home Folder
It determines the range for the client to access into.
The user can enter a directory name in this field. Then,
after clicking OK, the router will create the specific/new
folder in the USB diskette. In addition, if the user types “/”
here, he/she can access into all of the disk folders and files
in USB diskette.
Note: When write protect status for the USB diskette is
ON, you cannot type any new folder name in this field.
Only “/” can be used in such case.
Access Rule
Select the access right for the USB diskette.
When you finish the settings, simply click OK to save the configuration.
4
4
.
.
9
9
.
.
3
3
D
D
i
i
s
s
k
k
S
S
t
t
a
a
t
t
u
u
s
s
This page can display current using status of the USB diskette. If you want to remove the
diskette from USB port in router, please check the box of Safely Remove Disk first. And then,
remove the USB diskette later.
S Safely Remove Disk
Check this box and then you can remove the USB diskette
safely.
Manufacturer
Display the manufacturer of the disk.
Model
Display the type of the disk.
Size
Display the storage space of the diskette(s).
Status
Display current usage status of the diskette(s)
Update
Click this button to refresh the disk status.
4
4
.
.
9
9
.
.
4
4
D
D
i
i
s
s
k
k
S
S
h
h
a
a
r
r
e
e
s
s
This page can define the folder which will be shared while Samba File Sharing is enabled.
